MECHANICAL SERIES
| RECOMMENDED TRANSOM HEIGHT MM | S: 381 L: 508 |
| STARTING SYSTEM | Electric/Manual |
| WEIGHT KG *1 | S: 65 L: 63 |
| ENGINE TYPE | OHC |
| FUEL DELIVERY SYSTEM | Battery-Less Multi-Point Sequential Electronic Fuel Injection |
| NO. OF CYLINDERS | 3 |
| PISTON DISPLACEMENT CM3 | 490 |
| BORE X STROKE MM | 60.4 x 57.0 |
| MAXIMUM OUTPUT KW | 22.1 |
| FULL THROTTLE OPERATING RANGE RPM | 5,300–6,300 |
| STEERING | Tiller |
| CHOKE | - |
| OIL PAN CAPACITY LIT. | 1.5 |
| FUEL TANK CAPACITY LIT. | 25 |
| IGNITION SYSTEM | Digital CDI |
| ALTERNATOR | 12 V 14 A |
| ENGINE MOUNTING | Shear Mount |
| TRIM METHOD | Manual |
| GEAR RATIO | 2.09:1 |
| GEAR SHIFT | F-N-R |
| EXHAUST | Through Prop Hub Exhaust |
| PROPELLER SELECTION (PITCH)* | 9”–15” |
* Please inquire at your local Dealer for details of the propeller.
*1: Dry Weight: Including battery cable, not including propeller and engine oil
