MECHANICAL SERIES
| RECOMMENDED TRANSOM HEIGHT MM | X: 635 XX: 762 |
| STARTING SYSTEM | Electric |
| WEIGHT KG *1 | X: 275 XX: 284 |
| ENGINE TYPE | DOHC 24-Valve |
| FUEL DELIVERY SYSTEM | Multi-Point Sequential Electronic Fuel Injection |
| NO. OF CYLINDERS | V6 (55-degree) |
| PISTON DISPLACEMENT CM3 | 3614 |
| BORE X STROKE MM | 95 x 85 |
| MAXIMUM OUTPUT KW | 165.0 |
| FULL THROTTLE OPERATING RANGE RPM | 5,000–6,000 |
| STEERING | Remote |
| CHOKE | - |
| OIL PAN CAPACITY LIT. | 8.0 |
| FUEL TANK CAPACITY LIT. | - |
| IGNITION SYSTEM | Fully-transistorized |
| ALTERNATOR | 12 V 54 A |
| ENGINE MOUNTING | Shear Mount |
| TRIM METHOD | Power Trim and Tilt |
| GEAR RATIO | 2.29:1 |
| GEAR SHIFT | F-N-R |
| EXHAUST | Through Prop Hub Exhaust |
| PROPELLER SELECTION (PITCH)* | 15”–27.5” |
Counter Rotation Model Available
*All propellers are the 3-blade type. Please inquire at your local Dealer for details of the propeller.
*1: Dry Weight: Including battery cable, not including propeller and engine oil
